1. Equipment Introduction
1.1 Overview
The equipment used for circuit board processing can quickly and easily complete the processing of circuit boards.
After turning on the power on the back of the equipment, the equipment will automatically heat up when it starts. After reaching the preset temperature, it can be maintained at the set temperature. The equipped timer and temperature control meter can facilitate user operation.
1.2 Features
(1) Spraying method: The flushing system has good spray uniformity, and the nozzle can be easily removed and replaced after long-term use.
(2) Parameter setting: The equipment temperature and spray time can be set.
(3) Body design: The overall structure is tight, which simplifies the operation.
(4) Liquid circulation: The liquid can be circulated and sprayed to maximize the use of the liquid.


2. Equipment parameters
Power supply: AC 220v
Weight: 22kg
Dimensions (cm): 66.8*43.8*56.5
Operating environment: -25℃ to 40℃
3.Main body
No    Name
1    Power switch
2    Time relay
3    Temperature controller
No    Name
1    Nozzle
2    Card slot
3    (Internal) heating rod
No    Name
1    Power interface
2    Main power switch
4.Accessories
No    Name
1    Anhydrous sodium carbonate
2    Power cord
3    Rubber gloves
